1000VA APC Inverter with 12V, 88AH batteries metal cabinet and cable management
APC Home UPS 1000VA / 660W, Metal battery Cabinet, 2 year warranty on UPS by APC Provides maximum benefits
- World class tele support, 24 hours, 7 days a week
- 2 Year / 24 month Onsite Replacement Warranty on Home UPS
- 18 month Onsite Replacement Warranty on battery supplied by APC
- 4 Free Preventive Maintenance Visits for the battery supplied by APC during the 18 month warranty period
- Lightest in its class, compact and aesthetically designed
- Child and shock proof features offering complete safety
- Supports switchover time for computers
More Benefits
- Automatic changeover from Mains to UPS mode in less than 20 milli seconds
- Operates on wide input voltage
- High & Low input voltage protection for connected equipment
- Battery recharges even at very low input voltage
- A built - in holiday mode switch prevents battery discharge when not in use for a long time
| Technical Specifications |
| Model |
BI1000I |
HI800SQ / HI800SQBT |
| Capacity |
1000VA / 660W |
800VA / 500W |
| Output waveform |
Pure Sinewave |
Stepped approximation to a Sinewave |
| Voltage on Mains |
100 - 270V |
100 - 265VAC |
| Frequency(Input) |
47 - 53Hz |
47 - 53Hz |
| Voltage(on Battery) |
210V + / - 10% |
170 - 275VAC |
| Frequency(on Battery) |
50Hz + / - 1% |
50Hz + / - 1% |
| Transfer Time |
<20 milli seconds |
<20 milli seconds |
| Over Load Indication |
100% for 60 seconds, Indications Via LED & Audible alarm with 3 times restart |
| Charger |
Constant Power, 2 step charging Input voltage range 100 - 270V |
| Short circuit protection |
Multiple short circuit protection provided |
| Protection |
Overload, Short circuit, Low battery, Over charge, Main slow & High Input Voltage |
| Overall Dimensions |
| Model |
Depth mm +/- 3 |
Width mm +/- 3 |
Height mm +/- 3 |
| HI800SQBT (With Plastic Battery Cabinet) |
410 |
630 |
580 |
| To convert into inch multiply mm by 0.0394 ( 533 mm x 0.0394 = 21 inch ) |
| Load Supported |
| BI1000I |
HI800SQ |
| 5 |
5 |
| 4 |
3 |
| 2 |
1 |
