For the past 12 years Sun Frost refrigerators/freezers have been used in over 50 countries and have an excellent track record. Sun Frost DC vaccine refrigerators are very ruggedly constructed and will provide many years of reliable operation, even in the harshest environments. The Sun Frost RFVB DC vaccine refrigerator provides a means of storing vaccines and medical supplies without the use of fossil fuels. Not only is the need for a fuel supply eliminated, but the unit operates more reliably than kerosene powered refrigerators.

Features

• Most efficient refrigerator in its size range
• Runs on either 12 volt or 24 volt DC
• Lowest system cost: Fewer solar panels and batteries to purchase, transport, and install
• Rugged construction for remote service
• Rustproof cabinet and hardware, all copper cooling system prevents corrosion
• Easy to defrost and clean: more convenient than chest models
• Evaporator is unexposed - cannot be punctured during defrosting
• Condenser is easy to clean and minimally affected by dust and cobwebs
• Reliable: compressor is the only moving part - no fans are necessary
• Excellent temperature control
• Reserve cooling capacity: runs only 27% of the time in a hot 43oC (110oF) environment
• Most efficient DC vaccine refrigerator of its size tested and approved by the World Health Organization
• Packing Crate can be turned into a strudy table for the DC vaccine refrigerator

Dimensions
Vaccine Storage Capacity	38.7 litrers (as measured by WHO)
Freezer Dimesion	Volume 34 litres (1.2 cu. ft.) 10.2 x 66.0 x 50.8 cm (4 x 26 x 20 in.)
Refrigerator Dimesion	Volume 51 liters (1.8 CF) 16.5 x 66.0 x 50.8 cm (6.5 x 26 x 20 in.)
Energy Consumption
Room Temperature	21oC	32oC	42oC
Energy consumption (12 V)	14 amp hours/day	23 amp hours/day 0.28 kWh.day	36 amp hours/day 0.43 kWh/day
Energy consumption (12 V) making 2.2 kg ice/day		32 amp hours/day 0.38 kWh/day	51 amp hours/day 0.61 kWh/day
Refrigerator temperature	3oC	3oC	3oC
Freezer Temperature	-11oC	-9oC	-5oC
Running Current	4.5 amps for 12 volts system, 2.3 amps for 24 volt
Starting Current	15 amps for 12 volts system, 7.5 amps for 24 volts
Wiring should be designed for 15 amp. Load for 12 volts system, 7.5 amps for 24 volts system
