ATT SB V24- 250
Array Tech 24V/10A solar controller with MPPT Technology is an advanced maximum power point tracking (MPPT) battery charger for photovoltaic (PV) systems up to 250Wp. The controller provides the Industry's highest peak efficiency of 96% and significantly less power loss compared to other MPPT controllers.
Technical Specifications for Model No: ATT SB V24- 250
| SN |
Description |
Ratings/Remarks/Protections |
| 1. |
Solar Input Power |
250W |
| 2. |
System Voltage(DC) |
24V |
| 3. |
Battery Operating voltage(DC) |
21V-28V |
| 4. |
Solar input Current |
10A |
| 5. |
Battery Charging Current |
10A |
| 6. |
Peak Efficiency |
96% |
| 7. |
Maxi. Solar Open circuit voltage |
54V |
| 8. |
Solar: Overload, Short Circuit, High Voltage |
Yes |
| 9. |
Battery: High Voltage |
Yes |
| 10. |
Reverse Current/Surge Protection |
Yes |
